Description

Keyboard: Semi-weighted keyboard, in 73-key (E-E)Touch Curve: 4 curves + 1 FixedKeyboard Mode: Single, Split, DualTranspose: +/- 6 semitonesOctave: +/- 2 octaveTechnology: TMT (Tonewheel Modeling Technology)+ HDS (High definition sampling)Parts: 3 Fully independent (Upper, Lower, Pedals)Sound Sections: 4 independent layers (Organ, Sound1, Sound2, Pedals)Power Supply: AC100/240V ORGAN SECTIONTechnology: TMT (Tonewheel Modeling Technology)Polyphony: 91 (tone wheels)Harmonic Percussion: On/Off, Soft/Normal, Decay Fast/Slow, Harmonic 3rd/2ndVibrato/Chorus: Upper and Lower On/Off, V1/V2/V3/C1/C2/C3 mode selector, 4 PresetsRotary Speaker: On/Off, Fast Slow/Stop speed, Drive, 8 Presets + 1 Custom with user selection of model, mic setup, memphis style, stop position, drum and horn balance, rotor speeds, rise and fall time, direct level, output level and eq.Additional Controls: Audio routing, reverb send, octave shift, keyclick, crosstalk, hum level, preamp ao-28, key comp, swell modeOrgan Models: B3 (1938), C3 (1955) B3 (1967), BC (1936), B3 (1956), A100 (1961), Baroque Pipe, Romantic Pipe, Symph Pipe, Farf Organ, Vx OrganSOUND 1/2 SECTIONSTechnology: HDS (High Definition Sampling)Polyphony: 240Additional Controls: Audio routing, reverb send, octave shift, f. cutoff, f. resonance, attack, decay, release, control1, control2, brilliance, detune, velocity sensSounds: 119 (Pianos, E.Pianos, Synths, Pads, Strings, Choirs, Brass, Guitars, Chromatic Percs, Bells, Keyboards and others)PEDALS SECTIONTechnology Additional: TMT (Tonewheel Modeling Technology)+ HDS (High definition sampling)Controls: Audio routing, reverb send, octave shift, pedals sustain, f. cutoff, layer/split mode, velocity mode, thud modeBass Models: 22 (T.Wheel Bass, Baroque Bass, Romantic Bass, Symph Bass, Farf Bass, Vx Bass, Organ Bass, Acoustic Bass, Finger Bass, Fretless Bass, Picked Bass, Slap Bass, Rhod Bass, Dark Pk Bass, Synth Bass1-2-3-4-5-6, Fat Bass, DX Bass)EXT. ZONE 1/2/3 SECTIONSMaster keyboard: 3 External Zones assignable to Upper, Lower and Pedals parts.Additional Controls: On/Off, Volume, midi/usb port, midi channel, octave shift, program change, bank msb, bank lsbEFFECTSMulti Effects: 2 Insert (IFX1, IFX2) + 1 Master (MFX)14 Effect Types (Tremolo, Vibrato, Chorus, Flanger, Phaser, Wah, Amp, Delay, Ring Mod, PEq3, PEq5, GEq5, Comp, Simple Rot)108 Effect PresetsReverb: 13 Reverb Types (Small Room, Large Room, Small Hall, Medium Hall, Large Hall, Stage1, Stage2, Medium Plate, Large Plate, Spring 1, Spring 2, Tape 1, Tape 2)Master Eq: 3 band (Low, Mid, High) with programmable parametersINTERFACEDrawbars: 20 (9 Upper + 9 Lower + 2 Pedals)Controls: Modulation Wheel, Pitch WheelDisplay: 128 x 64 OLED displayData Memory: 396 Programs (99 Banks x 4 Programs)CONNECTIONSAudio: Main L(Mono)/R outs, Aux1/2 outs, Pedals out, Analog in, HeadphonesRotary Speaker: 11-pin socketMIDI: In/Out, Soft-Thru, Pedalboard InUSB: to Host (Audio/Midi), to Device (Pen drive, Battery Charger)Pedal: Exp Pedal, Damp Pedal, Rotary Switch, Foot Controller, Foot SwitchWeight11.5 kg – 25.57 LbsDimensionsHeight cm 108,9 – 42.87″Width cm 32,8 – 12.91″Depth cm 11,1 – 4.37″
